Contents
xi
Figures
Loading and Unloading a Data Cassette 52
Setting the Write-Protect Tab on a Floppy Diskette 61
Inserting and Removing a Floppy Diskette 62
System Unit Front Panel LEDs 79
Removing the Floor Stand 100
Disk Tray Positions 103
Removing the Storage Tray 104
Removing a Disk Filler Panel 105
Installing a CD-ROM or DDS Tape 106
Removing a Disk Filler Panel 107
Installing a Floppy Drive 108
Removing a Disk Filler Panel 109
Installing a Hard Disk Drive in Position 1 110
Removing the Disk Interconnect Board 111
Installing a Hard Disk Drive 112
Installing the Disk Interconnect Board 113
Installing the Storage Tray Assembly 114
Removing Main Tray Assembly 118
Replacing the Main Tray Assembly 120
Memory Connectors (Model C160L) 125
