SCSI Connections
Determining SCSI Bus Length
Subtotals: __________ + __________
Total SCSI Bus Length = __________
(Total single-ended SCSI bus length not to exceed 6 meters [19.6 feet])
Table 24 Bus Length Worksheet for Single-Ended SCSI Bus
SCSI Device
Internal SCSI Bus Length
meters (feet)
Device Internal Length
meters (feet)
External
Cable Length
meters (feet)
System Unit
1.5 (4.9) 1.5 (4.9) N/A
A2655A 0.3 (1.0)
C1520B 0.2 (0.7)
C1521B 0.2 (0.7)
C1700C 1.1 (3.6)
C1701C 0.3 (1.0)
C1704C 0.0 (0.0)
C1705C 0.0 (0.0)
C2213A 1.5 (4.9)
C2217T 1.3 (4.3)
