HP xw4400 Service And Technical Reference Guide

B Appendix B — SATA devices
This appendix describes how to use the Intel Matrix Storage Manager option ROM Configuration Utility
to set up and manage SATA RAID volumes.
NOTE If only a single HDD is attached, the Intel Matrix Storage Manager option ROM will not
execute. All associated messages will not be displayed.
The Intel Serial ATA AHCI BIOS always executes when RAID/AHCI is selected for the SATA
emulation mode. This BIOS is only used to support serial attached optical drives. When an HDD
is attached, the AHCI BIOS properly identifies the HDD that is connected to the appropriate SATA
port and displays Device not supported in this configuration. This message is expected and
does not indicate a problem.
ENWW 151

HP xw4400 Specifications

General

Processor	Intel Core 2 Duo
Chipset	Intel 975X
Memory	Up to 8 GB DDR2
Storage	SATA 3.0 Gb/s
Graphics	NVIDIA Quadro FX series
Operating System	Windows XP Professional
Expansion Slots	1 PCI Express x16, 1 PCI Express x1, 3 PCI
Ports	6 USB 2.0, 2 PS/2, 1 serial, 1 parallel, 1 RJ-45
Optical Drive	DVD-ROM
