HP xw4400 Service And Technical Reference Guide

Creating RAID volumes
Use the Intel Matrix Storage Manager option ROM Configuration Utility to create RAID volumes.
1. Press Ctrl+I when prompted to enter the Intel Matrix Storage Manager option ROM Configuration
Utility.
2. If required, see
Deleting RAID volumes on page 155 to make enough physical drives available to
create the desired RAID volume.
3. Use the up or down arrow key to highlight 1. Create RAID Volume, and press Enter.
4. Type the desired RAID volume name in the “Name:” field, and press Tab.
5. Use the up or down arrow key to select the desired RAID level in the RAID Level: field, then
press Tab.
6. Press Enter to display the Select Disks dialog.
7. Use the up and down arrow keys and Space to mark individual physical disks as members of the
volume.
8. Press Enter to exit the Select Disks dialog and return to the Create Volume Menu dialog.
9. If appropriate, use the up or down arrow key to select the Strip Size in the Strip Size: field, and
press Tab.
10. Type the desired volume size in the Capacity: field, and press Tab.
11. Press Enter to initiate volume creation.
12. When prompted, press Y to acknowledge the warning message and create the volume.
13. Return to step 3 to create additional RAID volumes, or use ↑ or ↓ to highlight 4. Exit, and press
Enter.
14. Press Y when prompted to confirm the exit.
154 Appendix B Appendix B — SATA devices ENWW

HP xw4400 Specifications

General

Processor	Intel Core 2 Duo
Chipset	Intel 975X
Memory	Up to 8 GB DDR2
Storage	SATA 3.0 Gb/s
Graphics	NVIDIA Quadro FX series
Operating System	Windows XP Professional
Expansion Slots	1 PCI Express x16, 1 PCI Express x1, 3 PCI
Ports	6 USB 2.0, 2 PS/2, 1 serial, 1 parallel, 1 RJ-45
Optical Drive	DVD-ROM
