HP xw4400 Service And Technical Reference Guide

To replace the side access panel, align the bottom groove of the side access panel with the bottom edge
of the chassis, rotate the side access panel toward the chassis and press firmly until the latch engages.
Front Bezel
1. Lift up on the two release snaps 1 located on the front bezel.
2. Rotate the front bezel away 2 from the chassis to remove the bezel.
Figure 4-7 Opening the front bezel
To replace the front bezel, align front bezel on the bottom and rotate in until it snaps into place.
Bezel blanks
To remove the bezel blanks:
1. Disconnect power from the system (
Predisassembly procedures on page 60) and remove the front
bezel (
Front Bezel on page 67).
2. Gently push the subpanel 1 out the back of the front bezel.
3. Remove the desired bezel blank by applying outward pressure on the subpanel 1 and pulling the
blank 2 away.
ENWW Steps for removal and replacement of components 67

HP xw4400 Specifications

General

Processor	Intel Core 2 Duo
Chipset	Intel 975X
Memory	Up to 8 GB DDR2
Storage	SATA 3.0 Gb/s
Graphics	NVIDIA Quadro FX series
Operating System	Windows XP Professional
Expansion Slots	1 PCI Express x16, 1 PCI Express x1, 3 PCI
Ports	6 USB 2.0, 2 PS/2, 1 serial, 1 parallel, 1 RJ-45
Optical Drive	DVD-ROM
