Figure 3-26 Welding the copper pipes
Charge nitrogen with a small pressure to protect pipes from oxidation while you
weld the copper pipes, as shown in Figure 3-27.
Figure 3-27 Soldering
----End
Example
When routing pipes from the top, do not route the refrigerant pipe over servers,
avoiding the impact brought by refrigerant leakage on the servers.
NetCol5000-A(025, 035) In-row Air Cooled Smart
Cooling Product
User Manual (600 mm Width) 3 Installation Guide
Issue 17 (2020-10-22) Copyright © Huawei Technologies Co., Ltd. 55
