Huawei Quidway S1700 Series User Manual

Quidway S1700 Series Ethernet Switches
Web User Manual 1 WEB Configuration
Issue 01 (2011-11-17) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
5
Menu Sub-Menu Description
tration
LLDP Configuring LLDP
IP General Configuring Ping
ARP Configuring ARP
Multicas
t
IGMP
Snoopoing
Configuring IGMP related parameters, such as general,
multicast router, IGMP member, Interface, forwarding entry
1.2.3 Buttons
The buttons that you usually use on the Web interface are described in this section.
Table 1-3 describes the buttons and functions.
Table 1-3 Button description
Button Action
Sets specified values to the system.
Cancels specified values and restores current values prior to pressing
“Apply.”
Click to test the corresponding testing.
Click to delete the selected data.
Click to reset the swtich.
Click to clear the statistics on the system.
Click to refresh the statistics on the system.
Click to reset the configuration settings to the factory defaults.
Click to query on the system.
1.2.4 Common Interface Elements
The elements that you usually use on the Web interface are described in this section.
Table 1-4 describes the common elements that you usually use on the Web interface.
Table 1-4 Common Interface Elements
Element Description
Button
