Quidway S1700 Series Ethernet Switches
Web User Manual 10 Management
Issue 01 (2011-11-17) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
103
Title Description
Trunk Type The type of Trunk.
Trunk Description A string that indicates the Trunk‘s description. If RFC 2863 is
implemented, the ifDescr object should be used for this field.
Trunk ID A string that contains the specific identifier for the Trunk from
which this LLDPDU was transm
System Capabilities
Supported
The capabilities that define the primary function(s) of the system.
System Capabilities
Enabled
The primary function(s) of the system which are currently enabled.
Management Address The management address protocol packet includes the IPv4
address of the switch. If no management address is available, the
address should be the MAC address for the CPU or for the port
sending this advertisement.
802.1 Extension
Information
Display IEEE 802.1 Extension Information associated with the
remote trunk.
Remote Port VID Identify the trunk's VLAN identifier associated with the remote
trunk.
Remote VLAN Name
List
Display all VLAN Names associated with the remote trunk.
Remote Protocol
Identity List
Display all Protocol Identities associated with the remote system.
802.3 Extension trunk
Information
Display IEEE 802.3 Extension Trunk Information associated with
the remote trunk.
802.3 Extension
Frame Information
Display IEEE 802.3 Extension Frame Information associated with
the remote trunk.
----End
10.2.5 Displaying Device Statistics
Use the Administration > LLDP (Show Device Statistics) page to display statistics for
LLDP-capable devices attached to the switch, and for LLDP protocol messages transmitted or
received on all local interfaces.
To display statistics for LLDP-capable devices attached to the switch:
1. Click Administration, LLDP.
2. Select Show Device Statistics from the Step list.
3. Select General, Port, or Trunk.
