Quidway S1700 Series Ethernet Switches
Web User Manual 1 WEB Configuration
Issue 01 (2011-11-17) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
3
Table 1-1 Home page
Title Description
1 Main Menu
2 Your location
3 System Information
1.2.2 Navigation Tree
The navigation tree consists of ten nodes: System, Interface, VLAN, MAC Address, Spanning
Tree, Traffic, Security, Administration, IP, and Multicast.
Table 1-2 Switch Main Menu
Menu Sub-Menu Description
System General Provides basic system description, system uptime, system
name, system location, system contact, system jumbo frame
and system EEE.
IP Displays and Sets VLAN and the IPv4 address for
management access and displays local MAC address, etc.
File
z
Upgrade: upgrade the firmware for switch.
z
Set start-up:Sets the startup file
z
Show/Delete:Shows the files stored in flash memory;
allows deletion of files.
z
Config file: Save/Upload/Download the config file of the
switch.
Time Manually setts the current time.
CPU
Utilization
Displays information on CPU utilization
Memory Usage Shows memory utilization parameters
Reset Restarts the switch immediately.
RFID QA information by Huawei factory, to confirm if the factory
device system is normal and to guarantee every device has the
right version.
