Quidway S1700 Series Ethernet Switches
Web User Manual 10 Management
Issue 01 (2011-11-17) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
99
----End
10.2.4 Displaying LLDP Remote Port Information
Use the Administration > LLDP (Show Remote Device Information) page to display
information about devices connected directly to the switch’s ports which are advertising
information through LLDP, or to display detailed information about an LLDP-enabled device
connected to a specific port on the local switch.
To display LLDP information for a remote port:
1. Click Administration, LLDP.
2. Select Show Remote Device Information from the Step list.
3. Select Port, Port Details, Trunk, or Trunk Details.
Figure 10-9 Displaying Remote Device Information for LLDP-Port
Table 10-9 Parameters of Displaying Remote Device Information for LLDP-Port
Title Description
Local Port The local port to which a remote LLDP-capable device is
attached.
Chassis ID An octet string indicating the specific identifier for the
particular chassis in this system.
Port ID A string that contains the specific identifier for the port from which
this LLDPDU was transmitted.
System Name A string that indicates the system’s administratively assigned
name.
