Quidway S1700 Series Ethernet Switches
Web User Manual 10 Management
Issue 01 (2011-11-17) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
100
Figure 10-10 Displaying Remote Device Information for LLDP-Port Details
Table 10-10 Parameters of Displaying Remote Device Information for LLDP-Port Details
Title Description
Local Port The local port to which a remote LLDP-capable device is
attached.
Chassis Type Identifies the chassis containing the IEEE 802 LAN entity
associated with the transmitting LLDP agent. There are several
ways in which a chassis may be identified and a chassis ID subtype
is used to indicate the type of component being referenced by the
chassis ID field.
Chassis ID An octet string indicating the specific identifier for the
particular chassis in this system.
System Name A string that indicates the system’s administratively assigned
name.
System Description A textual description of the network entity.
Port Type Indicates the basis for the identifier that is listed in the Port ID
field.
Port Description A string that indicates the port‘s description. If RFC 2863 is
implemented, the ifDescr object should be used for this field.
