Quidway S1700 Series Ethernet Switches
Web User Manual 1 WEB Configuration
Issue 01 (2011-11-17) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
6
Element Description
Page selection
button
Radio button
Check Box
Text box
Drop-down list
Help
refresh
1.3 Idle-Time
If you do not perform any operation on the web interface for a long time, you are logged out
and the longin page is displayed. If you need to continue operations, log in again.
Figure 1-1 shows the login page.
Default idle time is 20minites.
1.4 Save Configuration
After performing configuration, you need to save the configuration data.
If you do not save the configuration data, the configuration that you made will be lost after
modifying or refreashing.
1.5 Logout
After the configuration finished, sugguest to logout to ensure the system security.
Following is the 2ways to logout.
z
Click the button to close the web browser.
