Quidway S1700 Series Ethernet Switches
Web User Manual 12 Multicast Configuration
Issue 01 (2011-11-17) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
117
Title Description
Interface Version Sets the protocol version for compatibility with other devices on
the network. This is the IGMP Version the switch uses to send
snooping reports. (Range: 1-2; Default: 2) This attribute configures
the IGMP report/query version used by IGMP snooping. Versions
1 - 2 are all supported, and versions 2 is backward compatible, so
the switch can operate with other devices, regardless of the
snooping version employed.
12.1.5 Displaying Multicast Groups Discovered by IGMP
Snoopoing
Use the Multicast > IGMP Snooping > Forwarding Entry page to display the forwarding
entries learned through IGMP Snooping.
To show multicast groups learned through IGMP snooping:
1. Click Multicast, IGMP Snooping, Forwarding Entry.
2. Select the VLAN for which to display this information.
Figure 12-10 Showing Multicast Groups Learned by IGMP Snooping
Table 12-5 Parameters of Showing Multicast Groups Learned by IGMP Snooping
Title Description
VLAN An interface on the switch that is forwarding traffic to downstream
ports for the specified multicast group address.
Group Address IP multicast group address with subscribers directly attached or
downstream from the switch, or a static multicast group assigned to
this interface.
Source Address The address of one of the multicast servers transmitting traffic to
the specified group.
Interface A downstream port or trunk that is receiving traffic for the
specified multicast group. This field may include both dynamically
and statically configured multicast router ports.
----End
