Huawei Quidway S1700 Series User Manual

Quidway S1700 Series Ethernet Switches
Web User Manual 9 Security Measures
Issue 01 (2011-11-17) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
80
4. Click Query.
Figure 9-6 Showing Addresses Authenticated for Network Access
Table 9-4 Parameters of Showing Addresses Authenticatedd for Network Access
Title Description
Query By Specifies parameters to use in the MAC address query.
z
Sort Key – Sorts the information displayed based on MAC address,
port interface, or attribute.
z
MAC Address – Specifies a specific MAC address.
z
Interface – Specifies a port interface.
z
Attribute – Displays static or dynamic addresses.
Authenticated
MAC Address
List
z
MAC Address – The authenticated MAC address.
z
Interface – The port interface associated with a secure MAC address.
z
RADIUS Server – The IP address of the RADIUS server that
authenticated the MAC address.
z
Time – The time when the MAC address was last authenticated.
z
Attribute – Indicates a static or dynamic address.
----End
9.4 Filtering IP Addresses for Management Access
Use the Security > IP Filter page to create a list of up to 5 IP addresses or IP address groups
that are allowed management access to the switch through the web interface.
9.4.1 Creating a list of IP addresses authorized
To create a list of IP addresses authorized for management access:
1. Click Security, IP Filter.
2. Select Add from the Action list.
3. Enter the IP addresses or range of addresses that are allowed management access to an
interface.
