Quidway S1700 Series Ethernet Switches
Web User Manual 3 System Management
Issue 01 (2011-11-17) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
14
Title Description
IP Address
Mode
Specifies whether IP functionality is enabled via manual configuration
(Static), Dynamic Host Configuration Protocol (DHCP). If DHCP is
enabled, IP will not function until a reply has been received from the server.
Requests will be broadcast periodically by the switch for an IP address.
DHCP responses can include the IP address, subnet mask, and default
gateway. (Default: DHCP)
IP Address Address of the VLAN to which the management station is attached. Valid IP
addresses consist of four numbers, 0 to 255, separated by periods. (Default:
192.168.0.1)
Subnet Mask This mask identifies the host address bits used for routing to specific
subnets. (Default: 255.255.255.0)
Gateway IP
Address
IP address of the gateway router between the switch and management
stations that exist on other network segments. (Default: null)
MAC
Address
Show the Physical address for this switch.
Restart
DHCP
Click to restart DHCP service.
----End
3.3 Managing System Files
Use the System > File page to manage the switch system files, including upgrading the switch
operating software or configuration files, setting the system start-up files, etc.
3.3.1 Upgrade Firmware
Use the System > File (Upgrade) page to upgrade the firmware to use for system
initialization.
To upgrade the firmware for switch:
1. Click System > File, see Figure 3-4.
2. Select Upgrade from the Action list.
3. Set the corresponding configuration parameters, and then click Apply.
SeeTable 3-3 for the parameters of upgrade switch.
