2 Site Map
About This Chapter
This chapter describes the following topics: Panel Display, Switch Information, and swtich
health.
2.1 Panel Display
2.2 Displaying Switch Information
2.3 Switch Health
2.1 Panel Display
This section provides information about the device panel.
Click Device Summary in the navigation tree to open the Device Summary page. You can
view the panel tab page, as shown in Figure 2-1.
Figure 2-1 Front panel Indicators
The panel area on the Web interface displays information about each port of the selected
switch, including:
z
Number of ports
z
Operating mode of each port: Active, Duplex, and Flow Control.
You can place the cursor on a port to view the port number.
