Title Description
Port ID A string that contains the specific identifier for the port from which
this LLDPDU was transmitted.
System Capabilities
Supported
The capabilities that define the primary function(s) of the system.
System Capabilities
Enabled
The primary function(s) of the system which are currently enabled.
Management Address The management address protocol packet includes the IPv4
address of the switch. If no management address is available, the
address should be the MAC address for the CPU or for the port
sending this advertisement.
802.1 Extension
Information
Display IEEE 802.1 Extension Information associated with the
remote port.
Remote Port VID Identify the port's VLAN identifier associated with the remote port.
Remote VLAN Name
List
Display all VLAN Names associated with the remote port.
Remote Protocol
Identity List
Display all Protocol Identities associated with the remote system.
802.3 Extension Trunk
information
Display IEEE 802.3 Extension Trunk information associated with
the remote port.
802.3 Extension
Frame information
Display IEEE 802.3 Extension Frame information associated with
the remote port.
Figure 10-11 Displaying Remote Device Information for LLDP-Truck
Table 10-11 Parameters of Displaying Remote Device Information for LLDP-Truck
Title Description
Local Trunk The local Trunk to which a remote LLDP-capable device is
attached.
Chassis ID An octet string indicating the specific identifier for the particular
chassis in this system.
Trunk ID A string that contains the specific identifier for the Trunk from
which this LLDPDU was transmi
