Quidway S1700 Series Ethernet Switches
Web User Manual 10 Management
Issue 01 (2011-11-17) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
104
Figure 10-13 Displaying LLDP Device Statistics (General)
Table 10-13 Parameters of Displaying LLDP Device Statistics (General)
Title Description
Neighbor Entries List
Last Updated
The time the LLDP neighbor entry list was last updated.
New Neighbor Entries
Count
The number of LLDP neighbors for which the remote TTL has not
yet expired.
Neighbor Entries
Deleted Count
The number of LLDP neighbors which have been removed from
the LLDP remote systems MIB for any reason.
Neighbor Entries
Dropped Count
The number of times which the remote database on this switch
dropped an LLDPDU because of insufficient resources.
Neighbor Entries
Age-out Count
The number of times that a neighbor’s information has been
deleted from the LLDP remote systems MIB because the remote
TTL timer has expired.
