Quidway S1700 Series Ethernet Switches
Web User Manual 10 Management
Issue 01 (2011-11-17) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
105
Figure 10-14 Displaying LLDP Device Statistics (Port)
Figure 10-15 Displaying LLDP Device Statistics (Truck)
Table 10-14 Parameters of Displaying LLDP Device Statistics (Port/Trunk)
Title Description
Frames Discarded Number of frames discarded because they did not conform to the
general validation rules as well as any specific usage rules defined
for the particular TLV.
Frames Invalid A count of all LLDPDUs received with one or more detectable
errors.
Frames Received Number of LLDP PDUs received.
Frames Sent Number of LLDP PDUs transmitted.
TLVs Unrecognized A count of all TLVs not recognized by the receiving LLDP local
agent.
TLVs Discarded A count of all LLDPDUs received and then discarded due to
insufficient memory space, missing or out-of-sequence attributes,
or any other reason.
