Quidway S1700 Series Ethernet Switches
Web User Manual 10 Management
Issue 01 (2011-11-17) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
95
Table 10-5 Parameters of Configuring LLDP Interface Attributes
Title Description
Admin Status Enables LLDP message transmit and receive modes for LLDP
Protocol Data Units. (Options: Tx only, Rx only, TxRx, Disabled;
Default: TxRx)
Basic Optional TLVs Configures basic information included in the TLV field of
advertised messages.
z
Management Address – The management address protocol
packet includes the IPv4 address of the switch. If no management
address is available, the address should be the MAC address for
the CPU or for the port sending this advertisement. The
management address TLV may also include information about
the specific interface associated with this address, and an object
identifier indicating the type of hardware component or protocol
entity associated with this address. The interface number and
OID are included to assist SNMP applications in the performance
of network discovery by indicating enterprise specific or other
starting points for the search, such as the Interface or Entity MIB.
Since there are typically a number of different addresses
associated with a Layer 3 device, an individual LLDP PDU may
contain more than one management address TLV. Every
management address TLV that reports an address that is
accessible on a port and protocol VLAN through the particular
port should be accompanied by a port and protocol VLAN TLV
that indicates the VLAN identifier (VID) associated with the
management address reported by this TLV.
z
Port Description – The port description is taken from the ifDescr
object in RFC 2863, which includes information about the
manufacturer, the product name, and the version of the interface
hardware/software.
z
System Capabilities – The system capabilities identifies the
primary function(s) of the system and whether or not these
primary functions are enabled. The information advertised by
this TLV is described in IEEE 802.1AB.
z
System Description – The system description is taken from the
sysDescr object in RFC 3418, which includes the full name and
version identification of the system's hardware type, software
operating system, and networking software.
z
System Name – The system name is taken from the sysName
object in RFC 3418, which contains the system’s
administratively assigned name. To configure the system name.
