Quidway S1700 Series Ethernet Switches
Web User Manual 10 Management
Issue 01 (2011-11-17) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
97
Figure 10-6 Displaying Local Device Information for LLDP-General.
Table 10-6 Parameters of Displaying Local Device Information for LLDP-General.
Title Description
Chassis Type Identifies the chassis containing the IEEE 802 LAN entity associated
with the transmitting LLDP agent. There are several ways in which a
chassis may be identified and a chassis ID subtype is used to indicate
the type of component being referenced by the chassis ID field.
Chassis ID An octet string indicating the specific identifier for the particular
chassis in this system.
System Name A string that indicates the system’s administratively assigned name.
System Description A textual description of the network entity. This field is also
displayed by the show system command.
System Capabilities
Supported
The capabilities that define the primary function(s) of the system as.
System Capabilities
Enabled
The primary function(s) of the system which are currently enabled.
Refer to the preceding table.
Management
Address
The management address protocol packet includes the IPv4 address
of the switch. If no management address is
available, the address should be the MAC address for the CPU or for
the port sending this advertisement.
