Quidway S1700 Series Ethernet Switches
Web User Manual 7 Spanning Tree Algorithm
Issue 01 (2011-11-17) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
51
Figure 7-1 Configuring Global Settings for STP (STP)
Figure 7-2 Configuring Global Settings for STP (RSTP)
Table 7-1 Parameters of Global Settings for STP
Title Description
Basic Configuration of Global Settings
SpanningTree
Status
Enables/disables STP on this switch. (Default: Enabled)
Spanning Tree
Type
Specifies the type of spanning tree used on this switch:
z
STP: Spanning Tree Protocol (IEEE 802.1D); i.e., when this option is
selected, the switch will use RSTP set to STP forced compatibility
mode).
z
RSTP: Rapid Spanning Tree (IEEE 802.1w); RSTP is the default.
