Huawei Quidway S1700 Series User Manual

Quidway S1700 Series Ethernet Switches
Web User Manual 8 Rate Limit Configuration
Issue 01 (2011-11-17) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
66
To map CoS/CFI values to internal PHB:
1. Click Traffic, Priority, CoS to DSCP.
2. Select Add from the Action list.
3. Set the PHB for any of the CoS/CFI combinations.
4. Click Apply.
Figure 8-10 Configuring CoS to DSCP Internal Mapping
----End
To show the CoS/CFI to internal PHB map:
1. Click Traffic, Priority, CoS to DSCP.
2. Select Show from the Action list.
Figure 8-11 Showing CoS to DSCP Internal Mapping
----End
Table 8-7 Parameters of CoS to DSCP Internal Mapping
Title Description
CoS CoS value in ingress packets. (Range: 0-7)
