Figure 1-18 External connections of the cabinet installed with two service subracks
(underfloor cabling)
PDU
ODF
Fan tray
DDF
DC power
distribution cabinet
ODF
Fan tray
External Connections of the N63E-22 Cabinet Installed with Two Service
Subracks (xDSL)
Figure 1-19 and Figure 1-20 show the external connections of the N63E-22 cabinet installed
with two service subracks.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
