Figure 1-19 External connections of the cabinet installed with two service subracks (overhead
cabling)
PDU
MDF
DC power
distribution cabinet
MDF
ODF
Fan tray
Fan tray
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
1 Cabinet
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
26
