Pin Signa
l
Pin Signa
l
Port Pin Signa
l
Pin Signa
l
54 TIP10 38 TIP2 22 TIP21 6 TIP29
53 RING
10
37 RING
2
21 RING
21
5 RING
29
52 TIP9 36 TIP1 20 TIP22 4 TIP30
51 RING
9
35 RING
1
19 RING
22
3 RING
30
50 TIP8 34 TIP0 18 TIP23 2 TIP31
49 RING
8
33 RING
0
17 RING
23
1 RING
31
Daughter Board
The H801ASRB board supports a daughter board port, which can be installed with the
H806ASDA daughter board.
Figure 3-88 shows the position of the daughter board on the H801ASRB board.
Figure 3-88 Position of the daughter board on the H801ASRB board
Daughter
board
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
