Chapter 9 Troubleshooting
259
Alarm
Code
Alarm
Level
Alarm Name Cause/Treatment
0A1
Cold start
Parameter data error Cause : The data input range in the parameter area is not
appropriate.
This error occurs when the magnitude relationship
is apparently inappropriate such as when 300mm
was incorrectly input as the value of the soft limit
negative side while the value of the soft limit
positive side was 200.3mm.
Treatment : Change the value to the appropriate one.
0A2 Position data error Cause : 1) A move command was input when no target
position was set in the “Position” field of a
position No. in the position table.
2) The value of the target value in the “Position”
field exceeded the Parameter No.3 and 4 “Soft
limit set value”.
3) A target position was specified in the “Position”
field by relative coordinate in the solenoid valve
mode 2 of PIO pattern 5.
4) Pressing operation was specified while the
vibration suppress control function remained
effective.
Treatment : 1) Set the target position.
2) Change the target position value to the one
within the soft limit set value.
3) The target position cannot be set by relative
coordinate (incremental feed).
4) The vibration suppress control function and
pressing operation cannot be used concurrently.
Provide setting so that either of the functions is
effective.
0A3 Position command data
error
Cause : 1) The command value during direct numeric
specification exceeded the maximum set value.
2) Pressing operation was specified in the field bus
specification while the vibration suppress
function remained effective.
Treatment : 1) Exceeded command item code is displayed in
the detailed code. Input an appropriate value by
referring to these values.
Detailed Code
(Command Item Code)
Command Item
0F00 Target Position
0F02 Command Speed
0F04 Acceleration
0F06 Deceleration
0F08 Positioning Width
0F0C
Pressing Current
Limit Value
0F0D Control Signal
2) The vibration suppress control function and
pressing operation cannot be used concurrently.
Provide setting so that either of the functions is
effective.
0A4
Operation
release
Command counter
overflow
Cause : The number of input command pulses exceeded
the range of -134217728 to +134217728
(H'F8000000 to '07FFFFFF).
Treatment : Attempt to make the value of the electrical gear
ratio smaller (make the movement against the unit
bigger).
