Chapter 10 Appendix
316
Motor
Output
Lead
Maximum
Speed
Maximum
Acceleration/
Deceleration Speed
Minimum
Pressing
Force
Maximum
Pressing
Force
Rated
Pressing
Speed
Actuator
Series
Type
[W]
No. of
Encoder
Pluses
[mm]
Oriented
Direction
[mm/s] [G] [N] [N] [mm/s]
10
600
(at 50 to 600st)
550
(at to 650st)
485
(at to 700st)
430
(at to 750st)
385
(at to 800st)
345
(at to 850st)
310
(at to 900st)
280
(at to 950st)
255
(at to 1000st)
0.5 − − −
20
Horizontal/
Vertical
1200
(at 50 to 600st)
1105
(at to 650st)
970
(at to 700st)
860
(at to 750st)
770
(at to 800st)
690
(at to 850st)
625
(at to 900st)
565
(at to 950st)
515
(at to 1000st)
0.7 − − −
Horizontal 1.0 − − −
RCS3
(Slider Type)
SS8
(Note)
150 16384
30
Vertical
1800
(at 50 to 600st)
1660
(at to 650st)
1460
(at to 700st)
1295
(at to 750st)
1155
(at to 800st)
1035
(at to 850st)
935
(at to 900st)
850
(at to 950st)
775
(at to 1000st)
0.7 − − −
(Note) The model stated in the hatched area is applicable for the offboard tuning function (except for the setting for
the high acceleration/deceleration type if any).
For the off board tuning function, refer to the instruction manual for RC PC Software.
