Chapter 10 Appendix
341
Motor
Output
Lead
Maximum
Speed
Maximum
Acceleration/
Deceleration Speed
Minimum
Pressing
Force
Maximum
Pressing
Force
Rated
Pressing
Speed
Actuator
Series
Type
[W]
No. of
Encoder
Pluses
[mm]
Oriented
Direction
[mm/s] [G] [N] [N] [mm/s]
300
(at to 600st)
− − −
270
(at to 650st)
− − −
240
(at to 700st)
− − −
215
(at to 750st)
− − −
Horizontal
190
(at to 800st)
0.5
− − −
170
(at to 850st)
− − −
155
(at to 900st)
− − −
140
(at to 950st)
− − −
130
(at to 1000st)
− − −
120
(at to 1050st)
− − −
5
Vertical
110
(at to 1100st)
0.4
− − −
600
(at to 600st)
− − −
545
(at to 650st)
− − −
480
(at to 700st)
− − −
430
(at to 750st)
− − −
Horizontal
380
(at to 800st)
0.7
− − −
345
(at to 850st)
− − −
310
(at to 900st)
− − −
285
(at to 950st)
− − −
260
(at to 1000st)
− − −
240
(at to 1050st)
− − −
ISDB
ISPDB
(Slider Type)
M
(Note)
100
200
16384
10
Vertical
220
(at to 1100st)
0.6
− − −
(Note) The model stated in the hatched area is applicable for the offboard tuning function (except for the setting for
the high acceleration/deceleration type if any).
For the off board tuning function, refer to the instruction manual for RC PC Software.
