Chapter 2 Wiring
77
Power Supply Connector Model Remarks
Cable Side MSTB2.5/6-STF-5.08 Enclosed in standard package
Controller Side MSTB2.5/6-GF-5.08
Note 1 The input power voltage cannot be changed after the delivery. Supply the power
voltage that meets the specification.
Pin No.
Signal Name
Contents Applicable cable diameter
1
L1 Motor AC power input
2
L2 Motor AC power input
2mm
2
(AWG14)
3
L1C Control AC power input
4
L2C Control AC power input
0.75mm
2
(AWG18)
5
NC Unconnected
6
PE Protective ground line
2mm
2
(AWG14)
Note 2 Use a copper conducting cable with the temperature rating 60degC or more for a
cable.
Note 3 Tightening torque of the terminal screws should be 0.5 to 0.6N•m.
Note 4 Pealed length of a copper conducting cable should be 7mm.
Brake Power Supply
Connector
Model Remarks
Cable Side MC1.5/2-ST-3.5 Enclosed in standard package
Controller Side MC1.5/2-G-3.5
Pin No.
Signal Name
Contents Applicable cable diameter
BK+ 24V DC power supply input
PWR- 24V DC ground
0.5mm
2
(AWG20)
BK+
PWR-
24V
0V
