Display Removal on Top of 29U Rack
1. On the top of the 29U rack, loose and remove the six screws «A¬ (see
Figure 6-4).
2. Remove the top cover «B¬.
3. Pull the signal and power display cables through the top opening.
4. Loose and remove the screws «F¬ that maintain the safety retainers «D¬ (see
Figure 6-5 on page 6-4).
A
C
B
Figure 6-4. Removing of the Top Cover
Chapter 6. Display Exchange 6-3
