2. ____ Install the captive nuts on the rack for installing the NAS and the display.
See Figure 1-9 for the front and rear rack location, and Figure 1-11 on page 1-9
for installation.
28
25
25
Figure 1-9. Brackets and Captive Nuts Positioning for the NAS with Earthquake Feature
1
2
Figure 1-10. Brackets Installation
Installing the NAS and Its Modem
1-8
2220 Setup and Service Guide
