IBM 300 - Detail of Lower Plate Installation; Support Installation at the Rear of a 37 U Rack

4. ____ Install the NAS «C¬ on the lower plate.
5. ____ On the rear of the rack install the support «D¬ using the screws (PN
43G3084) «E¬ (see Figure 1-14).
A
B
A
Figure 1-13. Detail of Lower Plate Installation
Figure 1-14. Support Installation at the Rear of a 37U Rack
Installing the NAS and Its Modem
Chapter 1. Installing and Configuring the NAS and Its Modem 1-11
