2220 Front View Locations in 29U Rack
Power
Input 2
Power
Input 1
FAN 1
Service
Drawer
TPAs
Up to 8
NAS
FAN 2
CPA
Clock
Module
(Optional)
Figure A-3. 2220 Front View Locations with NAS Type 6563 Installed in 29U Rack
A-4 2220 Setup and Service Guide
