Note: The safety retainers are shown installed on the left and right of the
machine, but if you have a problem with the pedestal of the display,
they can be installed at the front and rear.
b. Slide the pedestal display under the safety retainers (see Figure 6-7 on
page 6-6).
D
E
F
Figure 6-6. Safety Retainers Installation
Chapter 6. Display Exchange 6-5
