MAP 0520: After Hard Disk Drive Exchange on NAS Based on 6563
001
– Run the advanced diagnostic tests using the following procedure.
v Insert the Diagnostics diskette in the diskette drive.
v Power on the Nways Switch administration station and the display using their
respective power ON/OFF switches located on the front panels.
v Do not press F1 when the icon appears.
v Several messages appear. Wait until the following window appears.
Diagnostic - Interactive Tests - Hardware Info - Utility - Quit - F1=Help
PC-DOCTOR 2.0 Copyright 1999 Watergate Software. All Rights Reserved.
Diagnostic tests that check the functionality of your PC.
Use the Cursor keys and ESC to move in menus. Press ENTER to select.
v Select the Diagnostics option in the title bar and press Enter.
v The following window appears:
Diagnostic - Interactive Tests - Hardware Info - Utility - Quit - F1=Help
Run Normal Test
Run Quick Test
CPU/Coprocessor
System Board
Video Adapter
Serial Ports
Parallel Ports
Fixed Disks
Diskette Drives
Other Devices
Interactive Tests
Zip Drive
LS-120 Drive
CD-ROM/DVD Drive
Memory Test - Full
Memory Test - Quick
Fixed Disk Optimized Test
PC-DOCTOR 2.0 Copyright 1999 Watergate Software. All Rights Reserved.
Use the Cursor keys and ESC to move in menus. Press ENTER to select.
v Select the Fixed Disks option, then press Enter.
v The following window appears:
Chapter 5. Nways Switch Administration Station FRU and Display Exchange Procedures 5-21
