4. ____ Install the display on the top of the NAS.
5. ____ Go to “Connecting the NAS to the Display and Keyboard in the 37U Rack”
on page 1-14.
NAS Installation into a 37U Rack (Earthquake Feature)
1. ____ Install the brackets (PN 43G3111) for the NAS if not already done. See
Figure 1-9 on page 1-8 for bracket positioning and Figure 1-10 on page 1-8 for
bracket installation.
A
B
A
Figure 1-7. Detail of Lower Plate Installation
Figure 1-8. NAS and Display Installation in a 37U Rack
Installing the NAS and Its Modem
Chapter 1. Installing and Configuring the NAS and Its Modem 1-7
