8. Go to “After FRU Exchange”.
After FRU Exchange
Use the following table to find the MAP you need to follow, according to the
FRU that you have exchanged.
Nways Switch
Administration Station FRU
Exchanged Action
Board or Battery
v Go to “MAP 0500: After Board or Battery Exchange on NAS Based on 6563”
on page 5-16.
Hard Disk Drive
v Go to “MAP 0520: After Hard Disk Drive Exchange on NAS Based on 6563”
on page 5-21.
Ethernet Adapter
v Go to “MAP 0510: After Ethernet Adapter Exchange on NAS Based on 6563”
on page 5-18.
Other FRU
v Go to “MAP 0530: After Other FRUs Exchange on NAS Based on 6563” on
page 5-28.
6
F
D
E
A
2
4
3
1
5
B
Figure 5-15. NAS Connectors
Chapter 5. Nways Switch Administration Station FRU and Display Exchange Procedures 5-15
