Table 3. SPCN Error Codes for I/O Subsystems (continued)
Error Code Description Action/
Possible Failing FRU
1nn1 1B03 +3.3 V load fault
1. Replace power supply 1, U0.dd-V1.
2. If power supply 2 is present, use power
supply 1 that was removed to replace power
supply 2.
3. I/O subsystem backplane, U0.dd-P1.
1nn1 1B04 -12 V load fault
1. Replace power supply 1, U0.dd-V1.
2. If power supply 2 is present, use power
supply 1 that was removed to replace power
supply 2.
3. I/O subsystem backplane, U0.dd-P1.
1nn1 2600 Pgood fault I/O subsystem backplane, U0. dd-P1.
1nn1 2603 Power domain fault I/O subsystem backplane, U0. dd-P1.
1nn1 2605 Pgood 1.8 V fault I/O subsystem backplane, U0.dd-P1.
1nn1 2606 Pgood 2.5 V fault I/O subsystem backplane, U0.dd-P1.
1nn1 3100 I2C controller fault I/O subsystem backplane, U0. dd-P1.
1nn1 3101 I2C bus fault I/O subsystem backplane, U0. dd-P1.
1nn1 3102 I2C interface fault I/O subsystem backplane, U0.dd-P1.
1nn1 3103 I2C interface fault I/O subsystem backplane, U0.dd-P1.
1nn1 3104 I2C interface fault I/O subsystem backplane, U0.dd-P1.
1nn1 3110 SES module fault on SCSI backplane 1 Replace the SCSI backplane, location: U0.dd-P3
1nn1 3111 SES module fault on SCSI backplane 2 Replace the SCSI backplane, location: U0.dd-P4
1nn1 3113 PCI bridge chip fault I/O subsystem backplane, U0.dd-P1.
1nn1 3114 I2C fault I/O subsystem backplane, U0.dd-P1.
1nn1 3115 Operator panel fault I/O subsystem backplane, U0.dd-P1.
1nn1 3118 SPCN VPD fault I/O subsystem backplane, U0. dd-P1.
1nn1 3121 I2C VPD fault I/O subsystem backplane, U0.dd-P1.
1nn1 7610 Blower 1 fault Blower 1, U0.dd-F1.
1nn1 7611 Blower 1 missing Blower 1, U0.dd-F1.
1nn1 7620 Blower 2 fault Blower 2, U0.dd-F2.
1nn1 7621 Blower 2 missing Blower 2, U0.dd-F2.
1nn1 7630 Blower 3 fault Blower 3, U0.dd-F3.
1nn1 7631 Blower 3 missing Blower 3, U0.dd-F3.
1nn1 7640 Blower 4 fault Blower 4, U0.dd-F4.
1nn1 7641 Blower 4 missing Blower 4, U0.dd-F4.
1nn1 8400 Configuration ID conflict
1. Check the RIO and the SPCN cabling.
2. Set the I/O type using the service processor
menus.
3. I/O subsystem backplane, U0.dd-P1.
224 Eserver pSeries 630 Model 6C4 and Model 6E4 Service Guide
