13. (Optional) If the standby Supervisor-1 Module is not in the powered down state, then put the standby
Supervisor-1 Module to out of service, using the out-of-service module slot command .
Where a slot indicates the chassis slot number in which the standby supervisor module resides.
switch(config)# out-of-service module 6
Refer the “Verification” on page 99 to verify that the Supervisor-1 Module configurations are
successfully applied to the Supervisor-4 Module.
To view the inventory information for modules from the DCNM Web UI, select Inventory > View >
Modules. The Modules window is displayed with a list of all the switches and its details for a selected
scope.
For more information, see the DCNM SAN Management Configuration Guide.
What to do next
Migrate the Crossbar Fabric-1 Switching Modules to Crossbar Fabric-3 Switching Modules. For more
information, see the “Nondisruptive Migration from Crossbar Fabric-1 Switching Modules to Crossbar
Fabric-3 Switching Modules” on page 117
.
Verification
Use the following show commands to verify the migration procedure for the Supervisor-4 Module:
• show version
• show module
• show interface brief
• show interface status
• show system redundancy status
The following is a sample output for the show version command on the Supervisor-4 Module:
switch# show version
Nexus Operating System (NX-OS) Software
TAC support: http://www.cisco.com/tac
Documents:
http://www.cisco.com/en/US/products/ps9372/tsd_products_support_serie s_home.html
Copyright (c) 2002-2019, Cisco Systems, Inc. All rights reserved.
The copyrights to certain works contained in this software are
owned by other third parties and used and distributed under
license. Certain components of this software are licensed under
the GNU General Public License (GPL) version 2.0 or the GNU
Lesser General Public License (LGPL) Version 2.1. A copy of each
such license is available at
http://www.opensource.org/licenses/gpl-2.0.php and
http://www.opensource.org/licenses/lgpl-2.1.php
Software
BIOS: version 2.6.0
kickstart: version 8.4(1)
system: version 8.4(1)
BIOS compile time: 05/17/2019
kickstart image file is: bootflash:///m9700-sf4ek9-kickstart-mz.8.4.1.bin
kickstart compile time: 6/30/2019 23:00:00 [06/15/2019 14:49:08]
system image file is:
bootflash:///m9700-sf4ek9-mz.8.4.1.bin system compile time:
6/30/2019 23:00:00 [06/15/2019 16:15:18]
Hardware
SAN384C-6 (10 Slot) Chassis ("Supervisor Module-4")
Intel(R) Xeon(R) CPU D-1548 with 14270332 kB of memory.
Processor Board ID JAE22440CB1
Device name: switch
Chapter 3. Installing the IBM c-type SAN Device99
