8 Implementing the IBM Storwize V5000 Gen2 with IBM Spectrum Virtualize V8.1
Storwize V5030F control enclosures support only the attachment of Storwize V5030F
expansion enclosures (Models AFF and A9F). Storwize V5000 expansion enclosures (Models
12E, 24E, 12F, 24F, and 92F) are not supported with Storwize V5030F control enclosures.
Storwize V5030F expansion enclosures are only supported for attachment to Storwize
V5030F control enclosures. Storwize V5000 control enclosures (Models 12C, 24C, 112, 124,
212, 224, 312, and 324) do not support the attachment of Storwize V5030F expansion
enclosures.
Table 1-5 shows the 2U expansion enclosures and 5U expansion enclosure mix rules. Shown
are the maximum # of Drive Slots per SAS expansion string without disks in the controller
itself.
Table 1-5 2U expansion enclosures and 5U expansion enclosure mix rules
The Storwize V5030 systems can be added to an existing IBM Storwize V5000 Gen1 cluster
to form a two-I/O group configuration. This configuration can be used as a migration
mechanism to upgrade from the IBM Storwize V5000 Gen1 to the IBM Storwize V5000 Gen2.
2078-312 IBM Storwize V5030
LFF Control Enclosure
32 GB or 64 GB 12 x 3.5-inch
2078-324 IBM Storwize V5030
SFF Control Enclosure
32 GB or 64 GB 24 x 2.5-inch
2078-AF3 IBM Storwize V5030F
All-Flash Array Control
Enclosure
64GB 24 x 2.5-inch
2078-12F IBM Storwize V5000
LFF Expansion
Enclosure
N/A 12 x 3.5-inch
2078-24F IBM Storwize V5000
SFF Expansion
Enclosure
N/A 24 x 2.5-inch
2078-AFF IBM Storwize V5030F
SFF Expansion
Enclosure
N/A 24 x 2.5-inch
2078-A9F IBM Storwize V5030F
High Density LFF
Expansion Enclosure
N/A 92 x 3.5-inch
5U
2U 012345678910
0 000 024 048 072 096 120 144 168 192 216 240
1 092 116 140 164 188 212 236 260 - - -
2 184 208 232 256 280 304 - - - - -
3276300324--------
4368----------
Model Description Cache Drive Slots
