Figure 18. Hole locations in the front of the rack
⢠1 Upper rail mounting bracket pin
⢠2 Lower rail mounting bracket pin
⢠3 Rack mounting screw hole
5. Ensure that the appropriate bracket pins are installed in the front and rear bracket of each rail.
Each rail comes with four medium pins preinstalled (two in the front bracket and two in the rear
bracket). Large and small pins are provided separately. Use the pins that are appropriate for the
mounting holes in your rack. See Table 8 on page 20.
Table 8. Selecting bracket pins for your rack
Mounting holes Bracket pins
Round,
unthreaded
Use the preinstalled medium pins.
Round, threaded Unscrew the medium pins and replace with the smaller pins that are supplied
with the rails.
Square Unscrew the medium pins and replace with the large pins that are supplied with
the rails.
6. At each end of the rail, grasp the tab 1 and pull îłrmly to open the hinge bracket (see Figure 19 on
page 21).
20
Storwize V7000 : Gen3 Quick Installation Guide for MTM 2076-724, 2076-U7B, 2076-12F, 2076-24F, and
2076-92F
