Unpacking an optional 5U expansion enclosure
Before you unpack an optional 5U expansion enclosure, ensure that you review and follow all related
instructions and safety notices.
Before you begin
CAUTION:
The weight of this part or unit is more than 55 kg (121.2 lb). It takes specially trained persons, a
lifting device, or both to safely lift this part or unit. (C011)
CAUTION: To avoid personal injury, before you lift this unit, remove all appropriate subassemblies
per instructions to reduce the system weight. (C012)
Important: Before you unpack, move, install, or service the 2076-92F expansion enclosure and its parts,
always complete the following tasks:
⢠Read and follow the safety notices and instructions, as described in âSafety notices and considerations:
2076-92F â on page 29.
⢠Read and follow the guidelines that are described in âWeight considerations: 5U SAS expansion
enclosureâ on page 34.
⢠Ensure that a suitably rated mechanical lift is available to support the weight of the expansion enclosure
when it is inserted into the rack for installation.
About this task
The 2076-92F expansion enclosure and most parts are shipped together in one large box. A tray on top of
the enclosure contains the front fascia (1U and 4U pieces), the cable management arm (CMA), and the
slide rail kit. Figure 24 on page 24 shows how the enclosure is packaged for shipment.
Figure 24. Tray containing expansion enclosure parts
24
Storwize V7000 : Gen3 Quick Installation Guide for MTM 2076-724, 2076-U7B, 2076-12F, 2076-24F, and
2076-92F
