9. Connect the front video cable to the system board.
10. Replace the fan cage assembly (see “Replacing the fan cage assembly” on page
173).
11. Replace the top cover (see “Replacing the top cover” on page 147).
12. Slide the server into the rack.
13. Reconnect the power cords and any cables that you removed.
14. Turn on the peripheral devices and the server.
Screws
Figure 176. Screw installation
Front video cable
Figure 177. Cable connection
Chapter 5. Removing and replacing components 227
