8. Carefully remove the LCD system information display panel out of the media
cage.
9. If you are instructed to return the LCD system information display panel,
follow all packaging instructions, and use any packaging materials for shipping
that are supplied to you.
Media cage
Retention bracket
Figure 196. Retention bracket removal
Media cage
LCD system information
display panel
Figure 197. LCD system information display panel removal
Chapter 5. Removing and replacing components 247
