2.5-inch HDD hot-swap backplane
Power / configuration cable
SAS signal cable
Power / configuration cable
2.5-inch HDD hot-swap
backplane (expander)
2.5-inch HDD hot-swap backplane
Power / configuration cable
SAS signal cable
SAS signal cable
Figure 255. Cable connection
SAS signal cables
Power / configuration
cables
SAS 0
SAS 1
SAS 0
SAS 1
SAS 1
SAS 0
Figure 256. Cable routing
296 System x3650 M5 Type 5462: Installation and Service Guide
