Table 7. Integrated management module error messages (continued)
v Follow the suggested actions in the order in which they are listed in the Action column until the problem
is solved.
v See Chapter 4, “Parts listing, Type 7377 server,” on page 125 to determine which components are
customer replaceable units (CRU) and which components are field replaceable units (FRU).
v If an action step is preceded by “(Trained service technician only),” that step must be performed only by a
trained service technician.
Message Severity Description Action
The Processor CPU
n Status has a Configuration
Mismatch.
(n = microprocessor number)
Error A processor configuration mismatch
has occurred.
1. Make sure that the installed
microprocessors are compatible
with each other (see “Installing
a microprocessor and heat sink”
on page 223 for information
about microprocessor
requirements).
2. (Trained service technician only)
Replace the incompatible
microprocessor.
The Processor CPU
n Status has Failed with
FRB1/BIST condition.
(n = microprocessor number)
Error A processor failed - FRB1/BIST
condition has occurred.
1. Check for a UEFI firmware
update.
Important: Some cluster
solutions require specific code
levels or coordinated code
updates. If the device is part of
a cluster solution, verify that the
latest level of code is supported
for the cluster solution before
you update the code.
2. Make sure that the installed
microprocessors are compatible
with each other (see “Installing
a microprocessor and heat sink”
on page 223 for information
about microprocessor
requirements).
3. (Trained service technician only)
Reseat microprocessor n.
4. (Trained service technician only)
Replace microprocessor n.
(n = microprocessor number)
116 IBM System x3630 M3 Type 7377: Problem Determination and Service Guide
