Table 7. Integrated management module error messages (continued)
v Follow the suggested actions in the order in which they are listed in the Action column until the problem
is solved.
v See Chapter 4, “Parts listing, Type 7377 server,” on page 125 to determine which components are
customer replaceable units (CRU) and which components are field replaceable units (FRU).
v If an action step is preceded by “(Trained service technician only),” that step must be performed only by a
trained service technician.
Message Severity Description Action
The Drive n Status has been
disabled due to a detected
fault.
(n = hard disk drive number)
Error A drive has been disabled because
of a fault.
1. Run the hard disk drive
diagnostic test on drive n.
2. Reseat the following
components:
a. Hard disk drive
b. Cable from the system
board to the backplane
3. Replace the following
components one at a time, in
the order shown, restarting the
server each time:
a. Hard disk drive
b. Cable from the system
board to the backplane
c. Hard disk drive backplane
(n = hard disk drive number)
The Drive n Status has
been removed from unit
Drive 0 Status.
(n = hard disk drive number)
Error A drive has been removed. Reseat hard disk drive n.
(n = hard disk drive number).
The Power Supply %1 has
Failed.
(%1 = CIM_PowerSupply.
ElementName)
Error
1. If the power-on LED is lit,
complete the following steps:
a. Reduce the server to the
minimum configuration.
b. Reinstall the components
one at a time, restarting the
server each time.
c. If the error recurs, replace
the component that you just
reinstalled.
2. Reseat power supply n.
3. Replace power supply n.
(n = power supply number).
Note: Make sure the technician
refreshes the VPD.
Chapter 3. Diagnostics 115
