Icom IC-7300 HF Plus - Voice TX Memory Recording and Playback

7
VOICE TX MEMORY OPERATION
7-2
Recording a Voice TX memory
D Playing back
1. Do steps 1 ~ 3 as described to the left to display
the VOICE TX RECORD screen.
2. Rotate
MULTI
to select the desired Voice memory
“T1” ~ “T8,” and then push
MULTI
.
3. Push
to start the playback.
L Playback is automatically terminated when all of the
recorded content in the memory is played back.
LTo stop while playing back, touch
.
4. To close the VOICE TX screen, push
EXIT
several
times.
You can record up to 8 Voice transmit memories of up
to 1 and a half minutes in each memory.
To transmit recorded content using a Voice TX
memory, rst record the desired message, as
described below.
L A user supplied SD card is required to use the Voice
TX memory function.
L You can also transmit the recorded content using an
external keypad (pp. 2-2, 12-8).
D Recording
1. Open the VOICE TX screen in a Voice mode.
L(Voice mode: SSB, AM or FM modes).
MENU
»
VOICE
L You can select [VOICE] on the MENU screen only
while in a Voice mode.
2. Touch [REC/SET].
• Opens the REC/SET screen.
3. Touch the “REC” item.
• Opens the VOICE TX RECORD screen.
4. Select the desired Voice memory “T1” ~ “T8.”
Touch to open
the MIC GAIN
adjustment
window
While Recording
Displays the input audio level
Adjust the Mic
gain so that the
“REC Level”
meter does not
reach 100%
5. Touch to start recording.
InformationL
• You can record up to 1 and a half minutes in each
memory.
• Without holding down [PTT], speak into the
microphone at your normal voice level.
• Previously recorded content is overwritten.
6. Touch to stop recording.
7. To close the VOICE TX screen, push
EXIT
several
times.
TIP: How to clear the recorded content
Touching the Voice memory for 1 second in step 4
above displays the Quick menu, and then touch
“Clear.”
Rotate
Push
• Opens the selected Voice memory.
