CONTROL COMMAND
14
• Memory keyer contents
Command : 1A 02
X
q: Channel data
w–&1: Text data
XXX
……
XX
01：M1
02：M2
03：M3
04：M4
•Character’scode
Character ASCII code Description
0–9 30–39 Number
A–Z 41–5A Alphabetical characters
a–z 61–7A Alphabetical characters
space 20 Word space
/ 2F Symbol
? 3F Symbol
, 2C Symbol
. 2E Symbol
@ 40 Symbol
^ 5E
e.g., to send BT, enter ^BT
✱
2A Inserts contest number (can be
used for 1 channel only)
• CW message contents
Command : 17 Up to 30 characters
While transmitting in the CW mode, or if the Break-in
function is ON, the transceiver transmits CW code
when the PC sends Command 17.
To send CW messages, the following character codes
are used.
•Character’scode
Character ASCII code Description
0–9 30–39 Number
A–Z 41–5A Alphabetical characters
a–z 61–7A Alphabetical characters
space 20 Word space
/ 2F Symbol
? 3F Symbol
. 2E Symbol
– 2D Symbol
, 2C Symbol
: 3A Symbol
’ 27 Symbol
( 28 Symbol
) 29 Symbol
= 3D Symbol
+ 2B Symbol
” 22 Symbol
@ 40 Symbol
•“FF”stopssendingCWmessages.
•“^”isusedtotransmitastringofcharacterswith
no inter-character space.
• Split offset frequency setting
Command : 1A 05 0012, 0013
1 kHz digit: 0–9 100 Hz digit: 0 (fixed) 100 kHz digit: 0–9 10 kHz digit: 0–9 10 MHz digit: 0 (fixed) 1 MHz digit: 0–9 Direction: 00: + direction 01: – direction
q
0XXXXXX
we
0
r
• SSB transmission bandwidth setting
Command : 1A 05 0050, 0051, 0052
XX
Lower edge
Higher edge
Lower edge
0: 100Hz
1: 200Hz
2: 300Hz
3: 500Hz
Higher edge
0: 2500Hz
1: 2700Hz
2: 2800Hz
3: 2900Hz
• RX HPF and LPF settings in each
operating mode
Command : 1A 05 0045, 0053, 0058, 0063, 0064
XXXX
LPF (upper side)
HPF (lower side)
HPF
0: through
1 to 20: 100 to 2000 Hz
LPF
5 to 24: 500 to 2400 Hz
25: through
Set the LPF value larger than HPF one.
D Data content description (continued)
